Antistatic Table Mat HOYATO-C-6009

web：www.hoyato.com name：Shenzhen Hoyato Protective Supplies Co.,Ltd

Antistatic Table Mat
HOYATO-C-6009

产品特点

Antistatic Table Mat is mainly made of anti (conductive) static material, dissipative static material, synthetic rubber and other materials.The surface is about 0.5mm thick dissipative electrostatic layer, bottom about 1.5mm thick conductive layer, 2mm double layer composite structure. The mat can be used for a long time with following features:Acid proof, alkali proof, anti chemical flux properties, and wear resistance, easy cleaning. Conductive Mat is made of electric material, synthetic rubber and other materials.

产品参数

1. tensile strength: 3.6Mpa

2. elongation at break: 188%

3. tear strength (right angle): 20.6KN/m

4. resilience (specimen is laminated by 6 layers): 14%

5. impact embrittlement temperature (no cut) -250c: no damage

6. compression permanent change rate 700Cx22h. compression 25%: 17.9

7. temperature resistance: 200 ℃

主要用途

Electronic semiconductor devices, electronic computer, electronic communication equipment and the integrated circuit and so on in the microelectronics industry production workshop and advanced laboratory, is mainly used for bedding desktop, line working mesa, shelves and making mat etc, and is suitable for the needs of different conditions and different environment.
